Whyte 5 in and 8, 12, 16, 24, output powered multiswitches
Whyte 5 input, one satellite powered multiswitches. These multiswitches Quad or Quatro LNB. LNBs.
5 input multiswitches are ideal for providing multiple satellite points in homes, apartments, rooms or offices from one fixed
dish. They can be used in both commercial and domestic applications. Many private customers now choose to have satellite
points in every room in the same way as mains outlets or network / internet points. Fitting a satellite provision in every room
means that multiple receivers can be used or receivers can be carried from one room to another if required. Multiswitches
are used in hotels to provide many TV channels for guests in their rooms. Schools, colleges and commercial buildings
all use multiswitches. These multiswitchers have a terrestrial input. The terrestrial signal is encoded onto the satellite cable
and can be accessed using the correct type of wall plate. If 3 aerials need to be fed into the multiswitch,
TV, FM and DAB, they can be combined using a
combiner and then the one output of the combiner feeds into the
terrestrial input of the multiswitch. Again the aerials are accessed in the rooms with an appropriate
wall plate.
Also check out the
EMP Centauri 5 input multiswitches.
To add a dish kit with quatro LNB,
use the following links -
Add a
60cm
60cm
80cm
90cm, or a heavy duty
60cm
70cm
Shipping options. Discounted shipping on all web orders.
UK -
mainland UK delivery is included in the price, (
VAT info.) (
Stock levels.)
so choose "
Mainland UK delivery included" - UK shipping option No 1 (or
priority options 4-7).
For "
UK offshore islands including Northern Ireland" many items including dishes up to 1.0m choose the £15 - UK option No 2.
International - Republic of Ireland - choose the £15 "
fixed price
multiple items to Eire" shipping option
International - within the EU - choose the £38 "
up to 5Kg by courier to EU countries" shipping option
International - outside of the EU - choose the "
International shipping quote by e-mail" shipping option.
Please note, although not guaranteed, many 1-3 day standard UK deliveries are actually arriving next day if the order
is received before our cut-off times but there is also a next day priority delivery option at only £6.50 if required
17 input multiswitches.
Multiswitches with 4 satellite inputs.
To order a EMP-Centauri MS17/8PIU
17 input and 8 output multiswitch click here
To order a EMP-Centauri MS17/12PIU
17 input and 12 output multiswitch click here
To order a EMP-Centauri MS17/12PIU
17 input and 16 output multiswitch click here
To order a EMP-Centauri MS17/12PIU
17 input and 24 output multiswitch click here
To order a EMP-Centauri MS17/12PIU
17 input and 26 output multiswitch click here
Important Information.
There is nothing difficult in fitting multiswitch systems. We can provide our customers with the technical
information needed. Mostly it is a wiring job and the multiswitch etc. side of it is easy to understand.
The cost of the parts is not expensive and the myths around this subject are false. It is easier
than you think. Satellite Superstore used to fit this equipment to schools, colleges,
blocks of flats etc. before we became 100% mail order. Out technical advice is based on
many years of experience with these products.
Dishes with quatro LNBs.
Click here for dishes with quatro LNBs.
3 and 4 sat quatro LNB / dish kits.
Click here for 3 and 4 satellite quatro LNBs dish kits and multibrackets.
Quatro LNBs.
Click here for quatro LNBs to go with your multiswitch.
Standard outlet plates.
Single output F connector outlet.
Surface back box.
Maxview twin F connector outlet plate
Low cost twin F connector outlet plate
UHF outlet plate.
F and UHF outlet plate.
Click here for standard outlet plates (then scroll down).
Outlet plates for multiswitches
(or after combiners)
TV, radio and satellite triplexed screened outlet plate.
Surface back box.
Triax TV, radio and twin satellite quad screened outlet plate
Triax TV, radio, return, phone and twin satellite outlet double plate
Triax Variable Attenuator
Click here to find outlet plates for multiswitches (then scroll down).
Modular standard outlet plates.
Double wall plate surround. Triax part number 304202 "2G grid"
F connector clip in module. Triax part number 304254
IEC (aerial female) clip in module. Triax part number 304250
IEC (aerial male) clip in module. Triax part number 304252
RJ45 network clip in module. Triax part number 304274
Telephone slave type clip in module. Triax part number 304270
Telephone master type clip in module. Triax part number 304268
1 module blanking plates. Triax part number 304256
HDMI outlet. Triax part number 304292
Surface back box.
Click here for modular standard outlet plates (then scroll down).
Modular outlet plates for multiswitches
(or after combiners)
Triax TV, radio and twin satellite quad
screened modular outlet plate
Surface back box.
Click here for modular outlet plates for multiswitches (then scroll down).
4 LNB cable.
This cable could be used with quad LNBs, quatro LNBs, two twin LNBs, or 4 single LNBs.
Each cable is 7mm as so it fits our screw on F connectors and our compression fit F connectors.
Order this cable on the
satellite cable page.
High Quality Triax Aerials.
As a main Triax dealer we can supply anything on the Triax web site at www.triax.co.uk
(if it is available.) Triax TV, FM and DAB aerails are below, however, if you need a a model not
listed, just find the part number on the Triax web site and we will order it for you. Deliveries
come in from Triax every few days and so the waiting time will be short for a special order item.
Multiswitches that will work with quad (and octo) LNBs.
These multiswitches work from a quatro,
quad or
octo LNBs. Manufactured in the EU.
This is the "Professional Range" from EMP-Centauri. High build quality. All multiswitches have gain controls on all inputs so that
levels can be balanced if required. (The economy range does not have adjustable gain. We only sell the professional range). The
specifications are impressive, Terr 40-862 MHz active (built in amp) 5-862 MHz passive (switchable). SAT 950-2300 MHz. Isolation
between inputs 20dB. (Instructions included). Power consumption 3W terr passive and 5W terr active. SAT gain 15dB adjustable.
The professional range is built in the EU to high standards of reliability. They even include instructions! (Most multiswitches don't).
General information -
5 input multiswitches are ideal for providing multiple satellite points in homes, apartments, rooms or offices from one fixed dish.
They can be used in both commercial and domestic applications. Many private customers now choose to have satellite points in every
room in the same way as mains outlets or network / internet points. Fitting a satellite provision in every room means that multiple
receivers can be used or receivers can be carried from one room to another if required. Multiswitches are used in hotels to provide
many TV channels for guests in their rooms. Schools, colleges and commercial buildings all use multiswitches. These multiswitchers
also have a terrestrial input. The terrestrial signal is encoded onto the satellite cable and can be accessed using the correct type
of wall plate. If 3 aerials need to be fed into the multiswitch,
5 input and 8 output (5X8) multiswitch. EMP-Centauri MS5/8PIU
Click here then scroll down to order
5 input and 12 output (5X12) multiswitch. EMP-Centauri MS5/12PIU
Click here then scroll down to order
5 input and 16 output (5X16) multiswitch. EMP-Centauri MS5/16PIU
Click here then scroll down to order
5 input and 20 output (5X20) multiswitch. EMP-Centauri MS5/20PIU
Click here then scroll down to order
5 input and 28 output (5X28) multiswitch. EMP-Centauri MS5/28PIU
Click here then scroll down to order
